Información Básica.
No. de Modelo.
BSDC180-250D1
Ubicación
Uso público
Número de interfaces de carga
Una pila con múltiples cargos
Modo de inicio
Operación Remota Móvil, Auténtico RFID
lugar de origen
zhejiang, china
estándar de interfaz
ccs1, ccs2, gb/t, chademo
potencia de salida
180kw 240kw 360kw 480kw 600kw
corriente de salida
ccs1/ccs2/gbt:0-250a:chadem0:0-125a
voltaje de entrada de ca
380v±15%,3p+n+peac
rango de tensión de salida
ccs1/ccs2/gbt:150vdc-1000vdc:chadem0:150vdc-500vdc
montaje
soporte de suelo
conexión de red
4g/ethernet
certificado
ce, cb, ukca, tuv, rcm
ocpp
ocpp1,6j
resistente al agua/al polvo
ip55, ik10
temperatura de funcionamiento
-30°c +50°c
garantía
2 años
Paquete de Transporte
cartón
Especificación
700 x 520 x 1800 (l*w*t)
Marca Comercial
beny
Origen
China
Capacidad de Producción
500000/año
Descripción de Producto
Top Brand in Protection for Solar PV, Battery Energy Storage and EV Charging System QUALITY PV PROTECTION PRODUCTS AND EV CHARGERS MANUFACTURER
We are a leading brand in annually producing hundreds of thousands of quality DC protection products and EV charging stations for complete and reliable solar photovoltaic, battery energy storage, and EV charging system. Certified by UL, SAA, CB, CE, TUV, UKCA, ISO, and RoHS,we have the first listed patented DC switch and produce creative solutions like the AFCI solution for rooftop fire protection, dynamic load balancing, and PEN fault detection EV charger.
We are a leading brand in annually producing hundreds of thousands of quality DC protection products and EV charging stations for complete and reliable solar photovoltaic, battery energy storage, and EV charging system. Certified by UL, SAA, CB, CE, TUV, UKCA, ISO, and RoHS,we have the first listed patented DC switch and produce creative solutions like the AFCI solution for rooftop fire protection, dynamic load balancing, and PEN fault detection EV charger.
Highlights :
*180kw/240kw/360kw/480kw/600kw Optional
* 2 Guns or 4 Guns or 6 Guns or 8 Guns or 10 Guns or 12 Guns (CCS1, CCS2,Chademo,GBT,)
* SPLIT DC EV CHARGER
* 7-inch LCD screen/LED light
* OCPP 1.6
* IP55
* 24 Months Warranty
* Cost-effective - separation units lower infrastructure and site preparation costs
* Adaptability - configurable power units support various electric vehicle models
* SPLIT DC EV CHARGER
* 7-inch LCD screen/LED light
* OCPP 1.6
* IP55
* 24 Months Warranty
* Space flexibility - split design allows flexible installation
* Scalability - adding units to meet growing demand without replacing the entire system* Cost-effective - separation units lower infrastructure and site preparation costs
* Adaptability - configurable power units support various electric vehicle models
FAST, EFFICIENT AND SAFE EV CHARGING STATIONBENY DC EV charging station has more powerful data calculation and processing capacity, smarter dispatching strategy, better heat dissipation performance and lower noise, and fully meets the requirements of high-power DC charging of vehicles with global standard DC interface.
The product has multiple protection design and active protective function, which can monitor all communication data in the charging process and give early warning to all kinds of abnormal charging to ensure the safety of users and vehicle
| Item | External Machine | Internal Machine |
| Structure Description | ||
| Shell Material | Sheet Metal | |
| Dimension | 600*230*1700(L*W*T) | 1400*800*1910(L*W*T) |
| Weight | ≤110KG | ≤800kG |
| Installation Method | Floor-Stand Type | |
| Cable Routing | Bottom Inlet Wiring, Bottom Outlet Wiring | |
| Cable Length | 5M | Custom |
| Charging Outlets | Double (CCS1+CCS1) Double (CCS1+CHADEMO) Double (CCS2+GBT) Double (CHADEMO+CHADEMO) Double (CCS2+CCS2) Double (CCS2+CHADEMO) Double (CHADEMO+GBT) Double (CCS1+CCS2) Double (CCS1+GBT) Double (GBT+GBT) | / |
| Connectivity Authorization | RFID, App | / |
| Screen | 7 Inch LCD Screen/LED Light | 7 Inch LCD Screen |
| Electrical Specification | ||
| AC Input Voltage | 150Vdc-1000Vdc | AC400V±15% ,3P+N+PEAC |
| Input Frequency | / | 50Hz/60Hz |
| Consumption | ≤15WH | ≤30WH |
| Rated Power | / | 150Vdc-100Vdc |
| Output Voltage Range | CCS2:150Vdc -1000Vdc | ≥95% |
| Output Current | 0~250A | / |
| Efficiency | ≥95% | / |
| Functionate Design | ||
| User Interface | Emergency Stop Button, LED Indicator, Card Swiping, Touch Screen | Touch Screen |
| Charging Stands | IEC 61851-21-2:2021; IEC 61000-6-2:2019; EN61000-6-4:2019; IEC 61851-1:2019; EN 61851-23:2014; EN 61851-24:2014 | |
| Communication | ||
| OCPP | OCPP1.6 | |
| Network Interface | Ethernet/4G | |
| Environment Condition | ||
| Application Place | Indoor/Outdoor | |
| Working Latitude | <2000m | |
| Working Temperature | -30 °C ~+50 °C | |
| Working Humidity | 5%~95% | |
| Protection Level | IP55 | |
| Natural Cooling | Forced-air Cooling | |
| MTBF | 24 Months Warranty | |
| Security Design | Over/Under Voltage Protection, Overlord Protection, Current Leakage Protection, Grounding Protection, Over Temp Protection, Lightening Surge Protection | |
These worldwide projects of EV chargers showcase how our innovative global EV charging station solutions have been applied to diverse environments, contributing to EV charging station construction.
Our EV charger supplies power to any electrical vehicle. The wall-mounted and floor-mounted design as well as its IP65 dust and waterproof housing make the EV chargers suitable for outdoor or indoor spaces. The output of our AC EV charger ranges from 16amps to 32amps. And the output power of DC fast EV charging is up to 600kW.
BENY is a long-running EV charger and PV products manufacturer with more than 30 years of experience. Our knowledge in manufacturing PV components ensures all of our EV chargers surpass your expectations in terms of service life and performance.
The robust build of our EV charger lets you satisfy various business goals while driving your brand.
BENY Electric attends all types of exhibitions every year,thus closely keeping contact with partnerships from different countries, learning the newest trend and the newest market demand,then improving our cutting-edge technology.
